N-580 Intel PCIe 4-Port Gigabit Network Adapter

Get a Quote ✎

2019/03/18

4x 1GbE RJ45 Port
PCIe 2.1 x4 Form Factor

Ordering Code: N-580
Part No: NE-D15-1410-00-00012
Solution: Intel I350-AM4

This PCIe 4-Port Gigabit Network Adapter is designed for desktops with available x4, x8, or x16 PCI Express slots. It supports high performance quad-channel networking and full duplex communication, achieving speeds up to 2000 Mbps while remaining compatible with existing Ethernet. Powered by the Intel i350 network controller, it offers performance-enhancing features and power management technologies, making it an excellent choice for data centers by reducing CPU utilization and power consumption. Additionally, the NC-SI feature allows it to serve as a secure networking port for server remote management. The adapter includes comprehensive software drivers for all desktop operating systems, including Microsoft Windows and Linux.

Features

Designed to meet PCI Express Specification Revision 2.1
Four 10/100/1000Mbps compatible RJ-45 Ethernet ports
Four-lane (or x4) PCI Express compatible with x4, x8 and x16 PCI Express slots
Fully Compliant with IEEE 802.3, IEEE 802.3u, IEEE 802.3ab
Supports 10/100/1000M data auto-negotiation
Teaming support
Jumbo Frame support
Half duplex at 10/100 Mb/s operation and full duplex operation at all supported speeds

Ordering Code	N-580
Description	Intel PCIe 4-Port Gigabit Network Adapter
Solution	Intel I350-AM4
Form Factor	PCIe 2.1 x4
Bus Width	x4 lane PCI Express
OS Driver Support	Windows 10/11(64 bit) Windows Server 2012 R2/2016/2019/2022 Linux 3.16 or later
Connectors	4x 1GbE RJ45 Ports
Data Rates	1Gb/100Mb/10Mb Ethernet
Support Low-Profile Bracket	Yes
Operating Temperature	0°C – 55°C
Storage Temperature	-40°C – 70°C
EMC Standards	CE, FCC
Dimensions	180.3L x 120.9W x 21.6H mm
Package Contents	1x Intel PCIe 4-Port Gigabit Network Adapter 1x Low-Profile Bracket 1x User Manual
Packing Information	Retail Box Packing 40 pcs/Carton Measurment: 60L x 48.5W x 34.5H cm G.W: 10.4 Kg ; N.W: 9.7 Kg
