G-210 BNC 2x1 Signal Switch
Get a Quote ✎
2015/03/19
- 2x BNC Ports
- 1x BNC IN/OUT Port
- Ordering Code: G-210
- Part No: YN-000-A110-12-00012
- Solution: NULL
G-210 lets you connect to 2 different composite video sources. Simply press the push button, you can choose which video sources to watch/capture. Bidirectional.
Features
- Share two BNC sources with one BNC devices or vice versa
- All BNC ports are impedance matched to support 75 Ohm equipment
- No power required
- No additional software needed
- Easy to use and install
| Ordering Code | G-210 |
|---|---|
| Description | BNC 2x1 Signal Switch |
| Connectors | 2x BNC Ports 1x BNC IN/OUT Port |
| Dimension | 112.3L x 68W x 30H mm |
| EMC Standards | CE FCC |
| Package Contents | 1x BNC 2x1 Signal Switch 1x User Manual |
| Packing Information | Retail Box Packing 80 pcs/Carton Measurment: 53L x 27W x 44H cm G.W: 16 Kg ; N.W: 15 Kg |
